HFJV1-1G46RL & HFJV1-E1G46R​ Vertical RJ45 Connectors Overview

1x1 vertical shielded Gigabit RJ45 MagJack with integrated transformers, IEEE-802.3 compliant, available in standard (HFJV1-1G46RL) and industrial-temperature versions (HFJV1-E1G46RL) for networking and industrial applications.

Key Features

• 1-port RJ45 Connector with integrated magnetics

• Supports 10/100/1000Base-T Ethernet

• Without LEDs

• Compatible with PoE / PoE+ (IEEE 802.3af/at)

• Low cross-talk & superior EMI suppression

• TOP-Entry Mounting

• RoHS-compliant, Halogen-free options available

• Shielded housing for noise immunity

Electrical Specifications

HFJV1-1G46RL / HFJV1-E1G46RL 1000 Base-T RJ45 Vertical Jack Circuit:

LINK-PP is a professional designer and Manufacturer of magnetic telecom and networking components. Founded in Shenzhen in 1997 and began to develop Discrete Transformer. With over 26 years of experience in innovation and technology leadership. Our main products include RJ45 Connectors, LAN Transformers, and SFP Modules. We focus on improving product reliability and durability.

Main Production Lines

◆ 10/100/1000/10GBase-T LAN Isolation Transformer and Filter

◆ Rj45 Modular Jack With Integrated 10/100/1000/10G Magnetics
◆ Magnetic Rj45 Jack with POE/ POE+; IEEE823.3af/ IEEE802.3at
◆ LAN Transformer With POE/ POE+; IEEE823.3af/ IEEE802.3at
◆ T1/E1,T3/DS3/E3/STS-1 Interface LAN transformer
◆ ISDN,HDSL,ADSL and VDSL Transformer and splitter

◆ Optical Transceivers
