AFBR-703SNZ | SFP+ Fiber Optic Transceiver Module | LC Duplex Pluggable

Ask Lasest Price
Brand Name :	LINK-PP
Model Number :	AFBR-703SNZ
Certification :	ISO 9001,ISO 14001,UL,SGS,REACH168
Price :	$0.11-$35
Payment Terms :	TT,NET30/60/90 Days
Supply Ability :	350K/Month
Delivery Time :	Stock

Add to Cart

Product Details
Company Profile

AFBR-703SNZ | SFP+ Fiber Optic Transceiver Module | LC Duplex Pluggable

Specifications:	AFBR-703SNZ
Product Class:	Fiber Optics
Product Family:	Optical Transceivers
Product Series:	SFP+
Product Name:	SFP+ Optical Transceivers
Status Available:	Active
RoHS:	RoHS-6 Compliance

Specifications:
Data Rate:	10 Gbd
Wavelength:	850nm
Maximun Distance:	300m
Fiber Type:	Multimode Glass
Emitter:	VCSEL
Voltage-Supply:	3.3V
Applications:	Ethernet
Connector Type:	LC Duplex
Mounting Type:	Pluggable,SFP+
Lead Free Status / RoHS Status:	Lead Free / RoHS Compliant
Moisture Sensitivity Level(MSL):	3 (168 Hours)

Feature Description:

• Optical interface specifications per IEEE 802.3ae 10GBASE-SR
• Electrical interface specifications per SFF Committee SFF 8431 Specifications for Enhanced 8.5 and 10 Gigabit Small Form Factor Pluggable Module “SFP+”
• Management interface specifications per SFF Committee SFF 8431 and SFF 8472 Diagnostic Monitoring Interface for Optical Transceivers
• LC Duplex optical connector interface confirming to ANSI TIA/EA 604-10 (FOCIS 10A)
• Compliant to Restriction on Hazardous Substances (RoHS) per EU and China requirements
• Class 1 Eye safe per requirements of IEC 60825-1 /CDRH
