XFGIB100JM-CLxu1-2MS | XFGIB100JM-CLGY1-2MS Magnetic RJ45 Jack LPJG4813HENL

Ask Lasest Price
Brand Name :	LINK-PP
Model Number :	XFGIB100JM-CLxu1-2MS
Certification :	UL,ROHS,Reach,ISO
Price :	Supportive
Payment Terms :	TT,NET30/60/90 Days
Supply Ability :	4600K.PCS/Month
Delivery Time :	Stock

Add to Cart

Product Details
Company Profile

XFGIB100JM-CLxu1-2MS | XFGIB100JM-CLGY1-2MS Magnetic RJ45 Jack LPJG4813HENL

XFGIB100JM-CLxu1-2MS | XFGIB100JM-CLGY1-2MS Magnetic RJ45 Jack LPJG4813HENL

XFGIB100JM-CLxu1-2MS = XFGIB100JM-CLGY1-2MS = LPJG4813HENL

Trader Part Number

XFGIB100JM-CLxu1-2MS

Price Break	Unit Price	Extended Price
1-5	AF	-
10-50	BE	-
100-500	C-12	-
1,000-2,500	Supportive	Competitive
5,000	Dynamic	Dynamic
10,000	Dynamic	Dynamic
50,000	Negotiable	Negotiable
100,000	Negotiable	Negotiable
500,000	Negotiable	Negotiable

Made in China Pin to pin

Cross Compatible

LPJG4813HENL

Manufacturer

LINK-PP China

Description

Rj45 Right Angle PCB Jack

Documents Available

PDF/3D/Step/IGS/Price/Cross

Quantity Available

200,000 PCS or 4 weeks

XFGIB100JM-CLxu1-2MS SPECFICATIONS: @25℃
1.Turn Ratio(±2%):
1CT:1CT
2.Inductance OCL:
350uH MIN @ 100KHz 0.1V 8mA DC Bias
3.Insertion Loss:
-1.0dB MAX @ 1.0-100MHz
4.Return Loss:
-18dB MIN @ 1-30MHz
-15dB MIN @ 30-60MHz
-12dB MIN @ 60-80MHz
-10dB MIN @ 80-100MHz
5.Cross talk:
-40dB MIN @ 30MHz
-35dB MIN @ 60MHz
-30dB MIN @ 100MHz
6.Common Mode Rejection:
-40dB MIN @ 30MHz
-35dB MIN @ 60MHz
-30dB MIN @ 100MHz
7.Hipot: 1500Vrms
