ELECTRICAL SPECFICATIONS @25℃
1.Turn Ratio(±2%): 1CT:1CT
2.Inductance OCL: 350uH MIN
@100KHz/0.1V,8mA DC Bias
3.Insertion Loss:
-1.0dB MAX @ 0.3-100MHz
-1.5dB MAX @100-125MHz
4.Return Loss:
-15dB MIN @ 40MHz
-13.1dB MIN @ 50MHz
-12dB MIN @ 60-80MHz
-10dB MIN @ 100MHz
5.Cross talk:
-45dB MIN @ 30MHz
-40dB MIN @ 60MHz
-35dB MIN @ 100MHz
6.Common Mode Rejection:
-43dB MIN @ 30MHz
-37dB MIN @ 80MHz
-33dB MIN @ 100MHz
7.CMRR: -30dB Min @1-100MHz
8.Hipot Test: 1500Vrms MIN
9.Operating Temperature Range: 0℃ TO 70℃

Why Choose Us
World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers

Quick Response---we are commited to deliver our quick response within one hour in working time and 24 hours in holiday.
Over 20 Years’ Experience---we’ve been in this field since 1997.and designed and produced wide range of products with our professional R&D team and Sales.
Competitive Price---we continuously strive to find ways of reducing our production costs, and passing the savings to our valued customers.
Quality Assurance---we are commited to provide high quality products and professional service. Which comply with CE RoHS.
Fast Delivery---kinds of shipment ways for your selection at lowest cost,3-5 days for samples.7-10 days for bulk purchase.
Free Sample---we offer you free samples to test the quality and dimensions before bulk purchase. We help you to controlyour risk.
Professional Certification---ISO 9001:2008,ISO 14001:2008, UL CE FCC Reach Certification, RoHS Compliance

LINK-PP is a professional designer and Manufacturer of magnetic telecom and networking components. Founded in Shenzhen in 1997 and began to develop Discrete Transformer. With over 26 years of experience in innovation and technology leadership. Our main products include RJ45 Connectors, LAN Transformers, and SFP Modules. We focus on improving product reliability and durability.

Main Production Lines

◆ 10/100/1000/10GBase-T LAN Isolation Transformer and Filter

◆ Rj45 Modular Jack With Integrated 10/100/1000/10G Magnetics
◆ Magnetic Rj45 Jack with POE/ POE+; IEEE823.3af/ IEEE802.3at
◆ LAN Transformer With POE/ POE+; IEEE823.3af/ IEEE802.3at
◆ T1/E1,T3/DS3/E3/STS-1 Interface LAN transformer
◆ ISDN,HDSL,ADSL and VDSL Transformer and splitter

◆ Optical Transceivers
